Description
Merits Health Products is driven to improve lives - every day, all over the world - We provide reliable, expertly engineered solutions for nearly every need. Our innovative designs constitute years of experience and research to fully understand the special needs of individuals. Through years of consultations, personal contacts and studies, Merits Health Products has adapted every way conceivable to satisfy our customers efficiently with quality and professionalism.
Key Details
- High Weight Capacity: Weight capacity 300 lbs.
- Different Seat Width Options: Available in 16” or 18” seat width, 20” optional.
- Adjustable Armrests: Height flip-up armrests, swing away footrests.
- Controller: Adjustable mounting bracket for controller, swing back mounting bracket optional.
- Portable Battery: Patented foldable battery bracket for improved portability.
- Foldable: Lightweight and foldable for easy handling, storage and transportation.
- Sharp Turning Radius: 23” turning radius allows access to narrow space.
- Maneuverability: Compact size and remarkable maneuverability.
- Programmable Controller: various choices of different performance to fit various needs.
- Durable: Rugged heavy duty casters and wheels.
Specifications
- Weight Capacity: 300 lbs.
- Product Weight: 146, 150, or 154 lbs.
- Driving Range: 18 mi.
- Max Speed: 4 mph
- Battery Type: 12V / U1 x 2 pcs
- Motor: DC 24V, 180W (Rating) / 630W (Max)
- Max Climbing Angle: 12°
- Turning Radius: 23"
- Ground Clearance: 4.5"
- Controller: PG VSI 50
- Charger: 5A off-board
- Front Wheel: 8" (200 x 50) PU tire
- Drive Wheel: 12 - 1/2” x 2 - 1/4” foam filled tire
- Rear Wheel: 12 - 1/2” x 2 - 1/4” foam filled tire
Dimensions
- Seat Width: 16", 18", or 20"
- Seat Depth: 16"
- Seat Height: 20"
- Backrest Height: 15"-19"
- Footrest Extension Length: 16"-21"
- Overall Length: 43"
- Overall Width: 22", 24", or 26"
- Overall Height: 36"
- Folded Width: 13"
Additional Information
