Experience All-Day Comfort and Confident Mobility with the Gemini Power Chair- Built for Independence and Versatility
Experience comfort, safety, and adaptability with this feature-rich power chair designed for individuals who value performance and support. The chair boasts a 20” wide captain’s seat that swivels, folds, and includes an adjustable headrest and backrest for maximum customization. A unique suspension system combined with a high-density foam seat ensures a smooth, cushioned ride even over uneven surfaces.
Maneuverability is enhanced with a sophisticated controller and large 14” aluminum cast drive wheels, offering both power and precision. Additional safety is provided by removable anti-tippers, while an aluminum footplate with height and angle adjustability accommodates various leg positions. Optional upgrades such as swingaway footrests, elevating legrests, and a power seat elevator provide even more flexibility and user convenience.

Essential Features That Deliver Comfort, Control, and Customization Every Day
- Adjustable Footplate: Aluminum footplate flips up and features customizable height and angle settings for optimal leg positioning.
- Spacious Captain Seat: 20” wide seat with swivel and fold-down functionality, plus adjustable headrest and backrest for personalized comfort.
- Smooth Suspension System: Unique shock-absorbing suspension paired with high-density foam seating delivers a consistently smooth ride.
- Powerful Drive System: Advanced controller and 14” aluminum cast drive wheels provide excellent control and maneuverability.
- Enhanced Safety: Equipped with removable anti-tippers to increase stability and prevent tipping on inclines or uneven terrain.
- Optional Leg Support Kit: Available swingaway footrests and elevating legrests with mounting bracket offer extra leg comfort and flexibility.
- Power Seat Elevator (Optional): Upgrade to a power seat elevator for easier transfers and elevated reach in daily activities. Adds 5-inches to the seat height.

Merits Gemini Heavy Duty Power Chair Specifications
Seat Width | 20 in. |
Seat Depth | 18 in. |
Overall Length | 41 in. |
Overall Width | 24 in. |
Overall Height | 45 in. |
Driving Range | 20 miles |
Maximum Speed | 5 mph |
Battery Type | 12V / 22NF x 2 (sealed lead-acid) |
Motor Output | 24V DC, 240W (Rated) / 950W (Max) |
Maximum Climbing Angle | 12° |
Turning Radius | 21 in. |
Ground Clearance | 4 in. |
Controller | PG nVR2-60A / Dynamic LiNX |
Battery Charger | 5A Off-board |
Weight Capacity | 450 lbs. and 350 lbs. (with seat elevation) |
Total Product Weight | 242 lbs. |
Front Wheel | 8.3" x 2.8" (210 x 70 mm) PU tire |
Rear Wheels | 14" (3.00–8) Foam-filled tires |

Merits Gemini Heavy Duty Power Chair Warranty
Frequently Asked Questions (FAQs)
What is the weight capacity, and how is it affected by the elevating seat option?
The Gemini P301 supports up to 450 lbs. with the standard seat. If equipped with the optional 5" power-elevating seat, capacity decreases to 350 lbs. due to mechanical limitations..
How far can the chair travel on a full charge, and what is the top speed?
With its 2 × 12 V/22NF batteries (approx. 50 Ah each), the Gemini delivers up to 20 miles of range per charge and reaches a maximum speed of 5 mph.
How maneuverable is the Gemini indoors and outdoors?
The chair maintains a tight 21-inch turning radius, ideal for indoor navigation, while its rear-wheel-drive design, 4-inch ground clearance, and 12° incline rating make it suitable for outdoor terrain.
What safety and control features are included?
The Gemini includes removable anti-tippers for enhanced stability. It comes with a programmable (Dynamic LiNX) or standard PG VR2‑60A controller, intelligent regenerative braking, and 14" foam-filled drive wheels for responsive control and safe stopping.
How Does the Optional Power-Elevating Seat Function?
The Gemini P301 is available with an optional 5-inch power elevating seat, ideal for reaching countertops, shelves, or interacting at eye-level.
