Heavy-Duty Performance with Flexible Bariatric Care
The RC 1000 is a robust bed with a 1000 lb. capacity and five-function electric control, making it a great bariatric bed option for the alternate care market. Its simple pull pin system allows caregivers to adjust the width from 39″ to 54″ for patients of various sizes and easy transport through 40″ door frames. The split frame design also aids in delivery to tight spaces at an economical price.
Purpose-Built Features That Make Every Day Easier
- Split Frame Design: Enables easy delivery and storage of the bed.
- 5 Functions: Includes Trendelenburg and cardiac chair adjustments for versatile positioning.
- Optional Integrated Scale: Allows one-button weighing in any position for convenient patient monitoring.
- Expandable Bed Deck: Permits transport through doorways as narrow as 40″, ensuring smooth movement.
- Wide Mattress Accommodation: Capable of accommodating mattresses up to 54″ wide, providing comfort.
- Padded Side Rails: 3-position, wing-type, padded side rails ensure safety and security.
- IV Pole and Foley Bag Holder: Conveniently designed with an IV pole and Foley bag holder for medical necessities.
- High Weight Capacity: Capable of supporting weights up to 1000 lbs, suitable for bariatric patients.
- Optional Trapeze: Additional option for added patient mobility and assistance.
Joerns Bariatric Healthcare Bed System RC 1000 Specifications
| Accommodates Mattresses In Various Widths | 37″, 39″, 42″, 48″, or 54″ for flexibility and comfort. |
| Bed Deck Length | Comes in two options, 84″ or 96″ with the optional extender, providing extended length as needed. |
| Overall Frame Size | Adjustable from 39.5″ to 56.5″ W x 91″ L, allowing customization to fit different spaces. |
| Bed Deck Height Range | Adjustable from 17″ to 30″, offering flexibility in positioning for ease of use. |
| Head/Footboard Width | Both measure 38″, providing a balanced and aesthetically pleasing design. |
| Total Weight | Weighs 570 lbs., ensuring stability and sturdiness. |
| Power Requirements | Operates on 115 VAC 60 Hz 10.5 AMP, offering standard power compatibility. |
| Warranty | Covered by a 5-year warranty for workmanship and materials, and a 1-year warranty for the electrical system, ensuring product quality and customer satisfaction. |
Joerns Bariatric Healthcare Bed System RC 1000 User Manual & Warranty
Frequently Asked Questions (FAQs)
What is the maximum weight capacity of the Joerns RC 1000 Bariatric Bed?
The RC 1000 is designed to safely support patients weighing up to 1,000 lbs., making it an excellent solution for bariatric care in homecare, long-term care, and other healthcare environments. Its heavy-duty construction provides dependable stability without compromising patient comfort.
Can the bed fit through standard doorways?
Yes. The RC 1000 features an expandable bed deck and split frame design, allowing it to be transported through doorways as narrow as 40 inches. This makes delivery, installation, and relocation much easier, even in homes or facilities with limited access.
What positioning functions does the RC 1000 offer?
The bed includes five electric positioning functions, allowing caregivers to easily adjust the head, foot, bed height, Trendelenburg, and cardiac chair positions. These features help improve patient comfort, support clinical care, and make transfers and caregiving more convenient.
Can the bed be adjusted for different patient sizes?
Absolutely. The RC 1000 features an adjustable-width bed deck that expands from 39 inches to 54 inches, accommodating a variety of bariatric patients. It also accepts mattresses in multiple widths and offers an optional 96-inch bed length for taller individuals.
Does the RC 1000 include an integrated patient scale?
An integrated scale is available as an optional upgrade. It allows caregivers to weigh patients with the touch of a button while the patient remains in bed, helping simplify routine weight monitoring without requiring transfers.
