Advanced Bariatric Pressure Relief with Expandable Low Air Loss Therapy
The Arise® 1000 EX is an expandable therapy system that provides pressure redistribution by combining low air loss with pulsation for patients weighing up to 1000 pounds.
With special features such as a power interruption alarm, a patient position sensor which optimizes support for seated patients (Fowler Boost) and a low friction and low shear cover, the Arise 1000 EX can provide increased caregiver peace of mind and patient comfort for your bariatric patients.
Engineered for Superior Bariatric Comfort & Clinical Performance
- Advanced Pressure Redistribution: Sixteen therapy cells (arranged in eight paired sections) evenly distribute patient weight to help reduce pressure points and enhance overall comfort.
- Deep Therapy Cell Support: Five-inch deep air cells provide stable support while helping prevent bottoming out for patients within the recommended weight capacity.
- Adjustable Width & Length: The control panel allows independent inflation and deflation of the six-inch side bolsters, supporting mattress widths of 36", 42", or 48". It also adjusts mattress length from 80" to 88".
- Power Outage Protection: A lower three-inch therapy cell continues to provide patient support during power interruptions for added safety.
- Durable, Easy-Clean Air Hose: Anti-kink air supply hoses are designed for reliable airflow, simplified cleaning, and long-lasting performance.
- 1,000 lb. Bariatric Capacity: Engineered to safely support patients weighing up to 1,000 lbs., making it ideal for demanding bariatric care environments.
- Customizable Therapy Modes: The control unit delivers true low air loss therapy with three operating modes—Autofirm, Pulsate, and Therapy—plus eight adjustable comfort levels to meet individual patient needs.
- Intelligent Fowler Boost Technology: An integrated patient position sensor automatically optimizes mattress support when the patient is in a seated or Fowler position, improving comfort and pressure relief.
Joerns Arise® 1000 EX LAL Bariatric Pressure Redistribution Mattress System Specifications
| Clinical Indications | Stage 1 – 4 Pressure Injuries; Moisture Management Required; Rehabilitation; Burns; Neurology; Dermatology; Amputations |
| Pain Management | AIDS; Arthritis; Oncology |
| Mattress Width | 36, 42, 48 in. |
| Mattress Length | 80, 88 in. |
| Mattress Depth | 8.5 in. |
| Mattress Weight | 28 lbs. |
| Maximum Weight Capacity | 1000 lbs. |
| Control Unit Dimensions | 13.5″ W x 11″ H x 7.5″ D |
| Control Unit Weight | 10 lbs. |
| Mattress Warranty | 2-Year Manufacturer Warranty |
| Control Unit, Electrical Components, and Cover | 1-Year Manufacturer Warranty |
Frequently Asked Questions (FAQs)
What patients is the Joerns Arise® 1000 EX designed for?
The Arise® 1000 EX is designed for bariatric patients weighing up to 1,000 lbs. It is recommended for individuals requiring advanced pressure redistribution and is suitable for managing Stage 1–4 pressure injuries, moisture management, rehabilitation, burns, neurology, dermatology, amputations, and pain management needs such as arthritis, oncology, and AIDS-related care.
How does the Arise® 1000 EX help prevent pressure injuries?
The system combines true low air loss therapy with pulsation technology to continuously redistribute pressure and improve patient comfort. Sixteen therapy cells evenly distribute body weight, while the low-friction, low-shear cover helps reduce skin friction and shear forces that can contribute to pressure injuries.
Is the mattress adjustable to fit different bariatric bed sizes?
Yes. The Arise® 1000 EX is specifically designed for the Joerns Bari10A bed frame and can expand or contract to accommodate mattress widths of 36", 42", or 48". It also adjusts in length from 80" to 88", allowing it to adapt to changing patient needs.
What therapy modes are available?
The control unit offers three therapy modes to support a variety of clinical needs: Autofirm for easier patient transfers and caregiving; Pulsate to provide alternating pressure redistribution; Therapy for continuous low air loss support. The system also features eight adjustable comfort levels and Fowler Boost, which automatically optimizes mattress support when the patient is in a seated position.
What safety features are included with the Arise® 1000 EX?
The Arise® 1000 EX includes several features designed to enhance patient safety and caregiver confidence, including a power interruption alarm, a lower support therapy cell that helps maintain support during power outages, anti-kink air hoses for reliable airflow, and an intelligent Fowler Boost position sensor that automatically adjusts support when the head of the bed is elevated.
