Safer, Smoother Transfers with Powerful Stand-Assist Support
The Proactive Medical Protekt® 500/600 Stand Assist Lift is designed to provide safe, efficient transfers for patients who can bear partial weight. Available in 500-lb. and 600-lb. weight capacity models, this stand assist lift combines a fast lift motor, secure sling attachment points, and an ergonomic design to help reduce the physical strain associated with patient transfers.
Its low-profile base easily slides beneath beds and furniture, while the wide 38-inch internal leg width allows caregivers to maneuver around toilets, chairs, and other common transfer areas with greater ease.
Powerful Features for Safer, More Confident Transfers
- 500- or 600-Lb. Weight Capacity: Choose between two models to accommodate different patient weight requirements, with support up to 500 lbs. or 600 lbs.
- Secure Sling Attachment: Multiple sling hooks provide flexible sling options and help promote safer, more controlled patient handling during transfers.
- Fast Transfer Motor: A high-speed lift motor helps reduce the time required for transfers, improving efficiency for both caregivers and patients.
- Long-Lasting 24V Battery: The 24-volt battery is designed to provide extended operating time, helping reduce downtime between charges.
- Hands-Free Base Adjustment: An ergonomically positioned foot pedal allows caregivers to open the lift base without using their hands.
- Locking Rear Casters: Dual rear locking casters include 4-inch rear wheels with brakes, while 3-inch dual front casters provide smooth maneuverability.
- Integrated Kneepad & Handlebar: A single-piece molded kneepad with an integrated handlebar provides comfortable positioning and added support during transfers.
- Adjustable Kneepad: The kneepad can be adjusted for height and depth to accommodate different users and improve positioning.
- Clip-Free Sling Hooks: Clip-free sling attachment points help simplify sling connections while improving safety and reducing transfer downtime.
- Modular Design: Clearly presented instructions and modular lift and electronic components make maintenance and part identification easier.
- Advanced Electronics: High-tech electronic controls include convenient auxiliary up/down lift controls for added operating flexibility.
Proactive Medical Protekt 500/600 Stand Assist Lift Specifications
| Protekt 500 | Protekt 600 | |
| Weight Capacity | 500 lbs. | 600 lbs. |
| Unit Weight | 119 lbs. | 132 lbs. |
| Base Extension Width – Closed | 26.4 in. | 26.4 in. |
| Mast Height | 41.7 in. | 41.7 in. |
| Base Length | 41.3 in. | 41.3 in. |
| Front Caster Height | 4.7 in. | 4.7 in. |
| Kneepad Depth Range | 2.8 in. | 2.8 in. |
| Kneepad Height Range | 20.2 – 23.7 in. | 20.2 – 23.7 in. |
| Footplate Width | 13.8 in. | 18.5 in. |
| Footplate Length | 14.5 in. | 16.6 in. |
| Base Opened Turning Diameter | 54.2 in. | 54.2 in. |
| Base Closed Turning Diameter | 50 in. | 50 in. |
| User Warranty | (3) years for the frame, (2) years on electronics, and (1) year battery | (3) years for the frame, (2) years on electronics, and (1) year battery |
Proactive Medical Protekt 500/600 Stand Assist Lift User Manuals & Brochures
Frequently Asked Questions (FAQs)
What is the weight capacity of the Protekt 500/600 Stand Assist Lift?
The Protekt Stand Assist Lift is available in two models. The Protekt 500 supports up to 500 lbs., while the Protekt 600 supports up to 600 lbs. Choose the model that best matches the user's weight and transfer requirements.
Who is the Protekt 500/600 Stand Assist Lift designed for?
The lift is designed for individuals who can bear partial weight and require assistance standing and transferring. It can help caregivers perform transfers between beds, chairs, toilets, and other common locations while reducing the physical effort required.
Can the Protekt Stand Assist Lift fit around toilets and chairs?
Yes. The lift features a 38-inch internal leg width, allowing it to maneuver around toilets, chairs, and other transfer areas. Its low-profile base can also slide beneath beds and furniture for greater accessibility.
What features make the Protekt 500/600 easier and safer to use?
The lift includes secure sling attachment points, an adjustable kneepad, integrated handlebar, locking rear casters, hands-free foot-operated base adjustment, and auxiliary up/down controls. These features are designed to provide better positioning, maneuverability, and control during transfers.
What is the warranty on the Protekt 500/600 Stand Assist Lift?
Both models include a 3-year warranty on the frame, 2-year warranty on electronics, and 1-year warranty on the battery.
