Merits Atlantis Power Wheelchair

Merits Health Products is driven to improve lives - every day, all over the world - We provide reliable, expertly engineered solutions for nearly every need. Our innovative designs constitute years of experience and research to fully understand the special needs of individuals. Through years of consultations, personal contacts and studies, Merits Health Products has adapted every way conceivable to satisfy our customers efficiently with quality and professionalism.

Key Details

• High Weight Capacity: Holds up to 600 lbs., with stylish design.
• Added Stability: Four seat posts provide more frame stability and durability.
• Wide Side: Extra-wide seat and extra-high back provides better support for obese users.
• Up To Date Footplate: Extra-wide footplate with handle hole.
• Powerful Motor: Super high power in-line motors easily negotiate 10° inclines.
• Long Drive Range: Drive range up to 31 miles on one charge.
• Adjustable: Height adjustable flip-up armrests.
• Recline: Semi reclining backrest.
• Safety: Anti-tippers add stability.
• Added Lights: Light reflectors.
• Seatbelt Safety: Seatbelt included.
• Added Traction: Rugged tires provide better traction.


Specifications

• Driving Range: 32 mi.
• Max Speed: 5 mph
• Battery Type: 12V/ 75AH x 2pcs
• Motor: DC 24V, 300W (Rating) / 1350W (Max)
• Max Climbing Angle: 8°
• Turning Radius: 31.5"
• Ground Clearance: 5"
• Controller: PG nVR2 60A DY LiNX
• Charger: 6A off-board, 8A optional
• Weight Capacity: 600 lbs.
• Total Weight: 315 lbs.
• Front Wheel: 9" pneumatic tire
• Drive Wheel: 12" pneumatic tire
• Rear Wheel: 12" pneumatic tire

Dimensions

• Seat Width: 24"
• Seat Depth: 21"
• Seat Height: 22"-23"
• Backrest Height: 23"
• Footrest Extension Length: 18"-20"
• Overall Length: 43"
• Overall Width: 27"
• Overall Height: 50"
