Recover Faster at Home with the Kinetec Centura Lite™ Shoulder CPM Machine
The Kinetec Centura Lite™ is a compact and lightweight Continuous Passive Motion (CPM) device designed specifically for shoulder rehabilitation in home settings. Engineered for maximum comfort, simplicity, and mobility, this home-use CPM machine helps patients regain range of motion after surgery or injury—without the need for in-clinic visits. Its intuitive design ensures easy setup and operation, encouraging consistent use and better recovery outcomes.
Perfect for post-operative shoulder therapy, rotator cuff recovery, and joint mobility improvement, the Centura Lite™ empowers patients to take control of their healing journey in the comfort of their own home.
Accelerate Shoulder Rehab at Home with the Kinetec Centura Lite™ CPM Device
- Extremely Compact And Lightweight: Ideal for home use and transportation. Enhanced, foam-covered chair for patient comfort.
- Essential Movements Featured: Abduction/Adduction (20° to 160°), Flexion/Extension (20° to 180°), Modular design allows for additional movements and upgrades.
- Kinetec Data Capture™ USB Technology Ready: Remote control with USB technology for data capture. Enables tracking patient progress and pre-programming rehabilitation protocols.
- Automatic Parameter Reset: Prevents incompatible range of motion for patient's condition.
- Load Reverse: Ensures patient safety during excessive force on the joint.
- Parameter Adjustment Lock: Allows locking of parameter adjustments.
- Precise Parameter Adjustment: Ensures precise adjustment of movement parameters.
- Modulation: Manual setting of ROM end-point based on patient tolerance.
- ROM By-Pass: Manual setting based on new patient tolerance for progressive range of motion work.
- Force Security Feature: Allows movement reversal following muscular contraction.
- Pauses: Pauses at movement limits for improved outcomes.
Kinetec Centura Shoulder CPM Machine Specifications
| Automatic Parameter Reset | Resets movement parameters when motion type changes to prevent incompatible ROM settings based on patient condition. |
| Load Reverse | Ensures patient safety by reversing movement when excessive force is detected on the joint. |
| Lockable Parameter Adjustments | Allows clinicians or caregivers to lock parameter settings to prevent accidental changes. |
| Precise Movement Control | Enables accurate and fine-tuned adjustment of all motion parameters for optimal therapy. |
| Modulation Mode | Manually set ROM end-points based on patient tolerance—ideal for beginning of sessions. |
| ROM By-Pass Mode | Adjusts ROM during the session to accommodate improved patient tolerance for progressive recovery. |
| Force Security Feature | Allows movement reversal in response to muscular contraction, enhancing patient safety. |
| Pause Function | Programmable pauses at movement limits to improve rehabilitation outcomes. |
| Speed Range | Adjustable between 50° and 140° per minute. |
| Device Weight | 297 lbs. |
| Device Dimensions | Length: 22″, Width: 39″, Height: 30″ — height is variable. |
| Patient Height Range | Compatible with patients from 4.6 ft. to 6.2 ft. |
| Minimum Patient Weight | Designed for users weighing at least 97 lbs. |
| User Warranty | Full 2 Year Manufacturer's Warranty |
Frequently Asked Questions (FAQs)
What types of shoulder movements does the Centura CPM support?
Abduction/Adduction: 20°–160° Flexion/Extension: 20°–180° Internal/External Rotation: approximately 60°–90° Combined Abduction with Rotation and optional horizontal abduction/adduction on select models
How does the Centura prioritize patient safety?
The CPM includes multiple built-in safety features: Load reverse reverses motion if excessive joint force is detected. Automatic parameter reset and lockout prevent settings that could be unsafe for the patient. Patient-controlled force-triggered reversal, and pause-at-limit features help avoid overstretching.
Can therapy sessions and ROM targets be customized or tracked?
Yes—each unit comes with: A programmable hand control supporting up to 16 customized therapy protocols. The Centura Lite™ version adds USB-compatible data capture, enabling progress tracking and remote adjustment.
What are the device’s speed, size, and weight specifications?
Speed: adjustable from 30° to 140° per minute (model-dependent). Weight: the Lite model weighs about 297 lb. Dimensions: approx. 27″ × 27″ × 35″ when set up.
Who is eligible to use this CPM device?
Suitable for patients typically between 4’2″ and 6’6″ (1.3–2.0 m) tall and above 97 lb. Always used under physician-prescribed rehabilitation protocols.
Is the Kinetec Centura Shoulder CPM easy to set up and use at home?
Yes, the Centura is designed with home use in mind—especially the Centura Lite™ model. It features: A lightweight, modular frame for easier transport and setup. Foam-covered, adjustable seating for patient comfort. An intuitive remote control with pre-programmed and customizable therapy options. Safety features like automatic parameter reset and lock-out to prevent accidental setting changes. This makes it ideal for patients transitioning from clinical therapy to independent recovery at home.
